Specifications

TUNER Section

Scale
12 note equal temperament
Detection Range
C1 (32.70 Hz) ~ C8 (4186 Hz), Using Sine Wave.
Reference Tone
C3 (130.81 Hz) ~ C6 (1046.50Hz), 3 Octave.
Tuning Modes
Meter Mode (AUTO), Sound Out Mode (MANUAL), Sound Back Mode (AUTO)
Calibration
410 ~ 480 Hz (1 Hz steps)
Detection Accuracy
+/- 1 cent
Sound Accuracy
+/-1 cent

METRONOME Section

Tempo Range
Quarter Note = 30 to 252 BPM
Tempo Setting
3 Types:Pendulum Step, Full Step, Tap Tempo
Time Signatures
Total 15 (0 – 9 beats, duplets, triplets, triplets without the center beat, quadruplets,  quadruplets without the center beats)
Tempo Accuracy
±0.3%

METRONOME Section

Terminals
Input (φ6.3mm, Mono-Standard Jack type), Headphones (φ3.5mm, Stereo-mini Jack type)
Internal Speaker
Dynamic Speaker (φ23 mm)
Power Supply
AAA battery (3.0 V) x 2
Battery Life
Tuner: Approximately 70 / 44 / 26 hours (Backlight: off / soft / auto, continuous A4 input, using manganese dry cell)
Metronome: Approximately 55 / 35 / 22 hours (Backlight: off / soft / auto, tempo 120, 4-beats, maximum volume, using manganese dry cell)
Dimensions
(W x D x H)
111 x 74 x 18 mm / 4/37 x 2.91 x 0.71 inches
Weight
106g / 3.74oz (Including battery)
Color Variations
Black (TM-50-BK), White (TM-50-WH)
Accessories
AAA battery (3.0 V) x 2 for verifying proper operation
Options
CM-200 Contact Microphone
*Even if a sound is within the detectable pitch range, detection may be unsuccessful for instrumental sounds that contain a large number of overtones or that decay rapidly.

* All products names and specification names are trademarks or registered trademarks of their respective owners.
* Appearance and specifications of products are subject to change without notice.
