Keyboard
- Keyboards
- 61 keys semi–weighted
Velocity sensitive and after touch are supported
Sound
- System
- Upgradable Operating System
RX (Real eXperience)
DNC (Defined Nuance Control)
Multitasking
Load while play feature
- Tone Generator
- KORG EDS (Enhanced Definition Synthesis) sound generator:
128 Voices, 128 OscillatorsFilters with Resonance
Three band EQ for each track
- Effects
- Up to 4 Stereo Digital Multi-Effect block systems
125 Master Effect types + 2 Global Effects
- Voice Processor Technology by TC Helicon® with 4 Effects
- Three-part Harmonizer, Reverb, Delay, plus Compressor, and EQ
- Sounds / Drumkits
- More than 1100, including Stereo Piano and GM/GS improved sound compatibility; more than 70 Drum Kits
User area: 512 Sounds, 128 Drum Kits
Defined Nuance Control (DNC) Technology
Digital Drawbars: 9 Footages
Full Sounds/Drumkits editing capability User PCM RAM Memory: 192 MB
- Full Sampling Editing
- Compatibility:
Load/Import of Korg, Wav, AIFF and SoundFont™; Export of Wav and AIFF; Edit, Time Slice, Compression Tool.
- Styles
- More than 400 preloaded Styles, freely reconfigurable
1200 available Style locations including the Favorite banks
Eight Style tracks, 4 Single Touch Settings, 4 Pads and one Style Setting per Style
Guitar Track 2 mode, Parallel and Fixed NTT
Style Record with Step Record, Track and Event Edit functions
Style controls: 3 Intros, 4 Variations, 4 Fills, Break, 3 Endings, Synchro Start/Stop, Tap Tempo/Reset, Bass Inversion, Auto Fill, Manual Bass, Memory, Accompaniment Mute, Drum Mapping, Snare & Kick Designation, STS Mode
- Chord Sequencer
- Real-time Style Chord Sequencer Recorder
- Performance / STS
- 320 Realtime Performance locations
STS: Memorize Keyboard tracks settings, up to 4 x 1200 Styles, up to 4 x SongBook entries,“My Setting” function
- Song Play
- Patented XDS Crossfade Dual Sequencer Player (Supported formats: MIDI, KAR, MP3 + lyrics, MP3+G)
2 Players with separate Select, Start/Stop, Home, Rewind and Fast Forward controls
X-Fader Balance control
Lyrics, Score, and Chord data can be displayed on screen, or on external video monitor
Markers
Jukebox function
- Mp3 Player / Recorder
- Double Mp3 Player and Mp3 Recorder
Real Time Transpose (+6/-5 semitones)
Tempo change (±30%)
Vocal Remover
Record MP3 files including Styles, SMF, Real Time Tracks, Pads, Microphone and Effects
- Sequencer
- Quick Record (Backing Sequence)
Multitrack and Step Record functions – Full-featured sequencer
16 tracks; Up to 200,000 events
SMF native format
- SongBook
- Fully programmable music database, based on Styles, SMF, Karaoke, MP3 with automatic selection of Style Play and Song Play modes
User-definable custom lists
Filtering and Ordering options
- Compatibility
- “i-Series” models: Styles
Pa series: Style, Performance, Program/Sound, Song, SongBook, Pad
- Multi Pad
- 4 Assignable Pads + Stop Button – Pad Record function
- General Controls
- Master Volume; Fade In/Out; Keyboard-Acc/Song Balance Volume; Ensemble; Octave Transpose; Master Transpose; Style Change; Quarter Tone and Arabic Scale memorized inside Performance/STS; Real-time controllers: Joystick (pitch + modulation); Mic Volume; Mic FX Volume; Mic On/Off; Mic Preset; Mic Harmony On/Off; 3 Assignable Switches; Tempo +/-; Tempo Lock; Dial; Search Function; Shift; Chord Scan; Split; Metronome On/Off; Sound Select
- Control Inputs
- Damper pedal (support half-pedaling with optional DS-1H pedal)
Assignable pedal/switch
- Outputs
- Audio Output:
Left/Mono, Right/Mono, Unbalanced
Headphone Output:
1 (in the front panel)Video Out:
1 RCA type
- Mic/Line Inputs
- 2 Unbalanced Jack; Left/Mono-Mic, with gain control and Right/Mono
- MIDI
- In, Out; standard Midi connectors
USB to Midi using the USB Device port
8 user definable MIDI Setups
- USB
- USB-MIDI Interface
Type A (TO DEVICE): 1 (Front)
Type B (TO HOST): 1 (Rear)
2.0 Hi Speed connections
- Mass Storage/Disk
- Micro SD, back panel slot
General Specifications
- Display
- Color TouchView™ 7” TFT display
- Clock
- Internal System Clock
- Power Consumption
- 20 Watt; 100-240v 50/60 Hz
- Dimensions
(W x D x H) - 1,030 x 378.3 x 138.8 mm / 40.55 x 14.89 x 5.46 inches (without music stand)
- Weight
- 10,76 kg / 23.72 lbs
- Accessories
- Manual, AC Power Cable, Music Stand, DVD-ROM
- Options
- EXP-2 – Expression/Volume Pedal
XVP-10 – Professional Expression/Volume Pedal
DS-1H – Damper Pedal
PS-1/PS-3 Switch Pedal
* All product, company, and standard names are trademarks or registered trademarks of their respective holders.
* Appearance and specifications of products are subject to change without notice. |
