Specifications

Keyboard:
61 notes with velocity

System:
OPOS – Objective Portable Operating System: Multitasking System, load while playing feature. Upgradeable Operating System. SSD Solid State Disk.

Tone generator:
HI synthesis (Hyper Integrated synthesis system)
62 voices, 62 oscillators
Filters with resonance.

Waveform Memory:
32 Mbyte PCM ROM (with Stereo Piano Sound).

Effects:
4 stereo digital Multi-Effect systems (90 effect types).

Programs:
More than 660 programs (including GM level 2 programs).
32 drum kits.
128 user programs + 64 user drum kits.

Styles:
Up to 304 Styles in Solid State Disk (256 preload +48 User).
All reconfigurable; 8 accompaniment tracks.
All Style Performances are programmable (includes 4 Single Touch Settings for each style).

Styles Controls:
4 Variations
2 Fills
2 Intros
2 Endings
Count In/Break
Synchro Start/Stop
Tap Tempo/Reset
Fade In/Out
Bass Inversion
Manual Bass
Tempo Lock
Memory
Accompaniment Volume
Accompaniment Mute
Drum Mapping
Snare & Kick Designation
Single Touch

General Controls:
Master Volume
Ensemble
Octave Transpose
Master Transpose
Split Point
Style Change
Tracks Volume
Quarter Tone Function
Programmable Slider
Joystick
Dial

Multi PAD:
4 assignable pads + Stop button.

Performance:
160 real-time Performances + up to 304 Styles Performances

Song Play:
XDS* Crossfade Dual Sequencer player – 2 Sequencers with separate Start/Stop,
Pause, ‘<< Rew’ and ‘>> FF’ controls.
Balance control. Lyrics are displayed on-screen.
Jukebox Function.
SMF Direct Player (format 0 and 1).

Song /Backing Sequence:
Easy record – 16 tracks – SMF format.

Control Inputs:
Damper Pedal, Assignable pedal/switch.

MIDI:
In, Out, Thru.

Data Storage:
SD (Secure Digital) data cards.

Display:
Backlit custom LCD.

Options:
EXP-2 Foot Controller, XVP-10 Exp/Volume Pedal,
PS-1 Footswitch, DS-1H Damper Pedal

Main Amplifier:
2×15 Watt

Speakers:
2 dual cone speakers
(in Bass Reflex Box- Auto Loudness control).

Audio Outputs:
Left/mono, Right.

Audio Inputs:
Left/mono, Right.

Power Consumption:
26 Watts

Dimensions:
41.5” W x 15.47” D x 5.9” H

Weight:
24.8 lbs
