- Keyboard
- 88 Weighted Hammer keys, Velocity Sensitive
- Sounds
- Factory: More than 950 sounds including Stereo Grand Piano and Stereo Upright (both with Damper Resonance) and GM 2 Sounds, 64 Drum Kits
- User
- 256 Sounds, 128 Drum Kits
Full editing of Sounds and Drum Kits
- Tone Generator
- 128 voices – Filters with Resonance – RX (Real Experience) technology
- Effects & EQ
- 4 Stereo Master Effects blocks
125 Effects types
Three band EQ for each track
Final Effects: Limiter and 4 band Parametric Equalizer
- Controllers
- Mini-Joystick
- Auto Accompaniment
- Factory: 420 preloaded Styles, freely reconfigurable
- Styles
- User: Up to 1,040 available Style locations including the Favorite/User banks
- Style Structure
- Eight Style tracks, 4 Single Touch Settings, one Style Setting per Style
- Style controls
- 3 Intros, 4 Variations, 4 Fills, Break, 3 Endings, Autofill, Synchro Start/Stop, Tap Tempo, Manual Bass, Bass Inversion, Memory, Accompaniment Mute, Kick & Snare Designation
Chord Sequencer
- Others
- Guitar Mode 2, Parallel and Fixed NTT, Style Record with Step Record, Track and Event Edit functions
- Performance/STS
- 240 Realtime Performance locations, Grand Piano special Performance
STS: Sound sets recalled by Styles
Up to 4 STS x Style, up to 4 STS x SongBook entry
- Keyboard Tracks
- Four Keyboard tracks (Upper 1, 2, 3, Lower)
- Song Play
- Player with Select, Start/Stop, Home, Rewind and Fast Forward controls
Jukebox function – Compatible with SMF (formats 0 and 1) and MP3 –
Lyrics (compatible with CDG), Score – Markers – MP3 Transpose (+6/-5 semitones) – MP3 Tempo Change (+/-30%)
- MP3 Recorder
- Record MP3 files including Style, SMF, Keyboard Tracks and Effects
- Sequencer
- Quick Record (Backing Sequence), Multitrack and Step Record functions
Full featured sequencer – 16 tracks – Up to 100.000 events – SMF format
- Song Book
- Fully programmable music database, based on Styles, SMF, Karaoke, MP3 with automatic selection of Style Play and Song Play modes – User-definable custom lists – Filtering options
- Search
- Style, Song, Performance, SongBook, Sound and Lyrics TXT
- Compatibility
- “i-Series”: Style
“Pa series”: Style, Performance, Sound, Song, SongBook
- General Controls
- Master Volume, Keyboard-Acc/Seq Balance Volume, Ensemble, Octave Transpose, Master Transpose, Tempo Lock, Quarter Tone Arabic Scale, User Scale memorized inside Performance/STS, Search, Lyrics, Score, Marker, Dial, Tempo, Metronome, Split
- Display
- 5″ TFT Color Graphical TouchView™
- Connections
- Control Input
- Assignable Pedal/Footswitch (Damper: support half-pedaling with included DS-2H pedal)
Headphones/Audio Out: Unbalanced Stereo Jack
- MIDI
- USB to Midi using the USB Device port – 8 user definable MIDI Preset
- USB
- USB-MIDI Interface – 2.0 Hi Speed connections
To Device: 1 (Rear) – To Host: 1 (Rear)
- Mass Storage/Disk
- USB
- Amp/Speaker System
- Amplification: 25W x 2
Speakers: 100 mm x 2 Double Cone Speakers in Bass Reflex Box
- Power
- Power Supply: AC 100-240 V
Power Consumption: 26 Watt
- Dimensions (W x D x H)
- 1,312 mm x 389 mm x 146 mm/51.65” x 15.31” x 5.75” without music rest
- Weight
- 15.1 kg / 33.29 lbs
- Included Items
- Music Stand, Accessory DVD (including Video Manual), External Power Supply Adapter and Power Cable, DS-2H Damper Pedal (support half-pedaling)
- Accessories
- ST-H30-BK Keyboard stand with damper pedal support
DS-1H Damper Pedal (support half-pedaling)
EXP-2, XVP10 Volume/Expression Pedal
PS-1, PS-3 Pedal Switch
