- Sound Generation
- Analog Modeling Synthesis System
- Synthesizer Programs
- Multi Timbres
- 2 (max, Split/Dual Mode)
- Maximum Polyphony
- 4 voices
- Structure
- 2 Oscillator + Noise Generator
- Multi Mode Filter (-24dB/oct LPF, -12dB/oct LPF/BPF/HPF)
- EG ×2
- LFO ×2
- Virtual Patch x4
- Vocoder Programs
- Maximum Polyphony
- 4 voices
- Structure
- 1 Oscillator + Noise Generator
- EG ×1
- LFO ×2
- 8 Channels vocoder
- Level and pan of each channel can be edited
- Formant Shift function
- Programs
- 256 programs (192 Presets / 64 Users)
Up to eight favorite programs can be registered
- Effects
- Modulation effects: flanger / chorus, phaser, ensemble (3 types)
Delay: stereo, cross, L/R (3 types)
Equalizer
- Arpeggiator
- 6 types (UP, DOWN, ALT1/2, Random, Trigger), Step Arpeggiator functio
- Controls
- Real-Time control knob x5, Arpeggiator ON/OFF
- Keyboards
- 37-keys (mini-keyboard, velocity sensitive)
- Inputs
- AUDIO IN 1 CONDENSER (with MIC/LINE switch, +5V, mini phone jack)
AUDIO IN 1 DYNAMIC (with MIC/LINE switch, 1/4” phone jack)
AUDIO IN 2 LINE (1/4” phone jack)
- Outputs
- L/MONO, R (1/4” phone jacks)
Headphones (1/4” stereo phone jack)
- MIDI
- IN, OUT, THRU
- Amp Output / Speaker
- 3 W / 4 cm x 1, 0.5 W / 3.5 cm x 2
- Display
- 3 characters x1 line with 8 segment LED
- Power Supply
- DC 9V (AC adapter), or six AA alkaline batteries (sold separately)
- Battery Life
- Approximately 4 hours or more (when using alkaline batteries)
- Dimensions (W x D x H)
- 524 x 232 x 70 mm / 20.63″ x 9.13″ x 2.76″
- Weight
- 2.5 kg / 5.51 lbs. (without batteries and included microphone)
- Included Items
- AC adapter (DC 9V), Condenser Microphone
